1.42
HYDRAULICS
Load control valve (55) The load control valve for the lift cylinder is fitted in the pressure oil supply lines, between the lift section (29) and the lift extension cylinder (54). The valve prevents any load movement in the event of hose bursts or leakage. If the valve is defective, a complete new cartridge must be fitted. The load control valve is factory set and should never be dismantled or adjusted except for resealing.
Key to Load Control Valve 1.
From the lift section (29)
2.
Lift cylinder (rod side)
3.
Lift cylinder (full bore side)
4.
From the lift section (29)
5.
Pilot pressure
6.
Supply pressure
7.
Pressure relief
