1. USER INSTRUCTIONS
GENERAL INFORMATION This use and maintenance handbook will guide you in coming to grips with your machine, its use and its maintenance. To keep your machine in perfect and reliable condition for as long as possible, make sure you carry out all scheduled maintenance operations. If you use it daily, make sure you lubricate it once a week. IMPORTANT: Check the tightness of the bracket after 10, 50 hours then every 100 hours. All the screws needing to be retightened must be inspected, changed if necessary, cleaned and smeared with loctite. Tighten the screws to the tightening torque specified in the table below. Tightening torque (Nm) Thread M8 M 10 M 12 M 14 M 16 M 18 M 20 M 22 M 30 x 150 M 40 x 150
8.8 21 42 72 114 174 240 340 455 500 500
Class of bolt 10.9 29 58 101 160 245 340 475 640
12.9 35 70 121 193 295 405 570 765
CLEANING THE MACHINE When using a high pressure cleaner, do not get too close to the machine and do not direct the jet of water towards any of the electrical parts, filling holes etc... SAFETY On page 12, you will find a list and description of the precautions which must be taken for the safety of the user and others. Before using the machine, read all the safety instructions and follow the corresponding advice and suggestions. The safety conditions are only guaranteed if the machine delivered matches the type of machine recommended in the current price list. SPARE PARTS Only use spare parts and accessories which comply with the manufacturer’s recommendations. Do not modify your machine and its accessories (mechanical, electrical, hydraulic and pneumatic characteristics) yourself and do not have them modified by other persons unless you have prior written permission to do so from your manufacturer. If you do not follow these rules, you may make your machine dangerous. The manufacturer will not be held at all liable for any resulting damage or injuries. GUARANTEE If the standards and instructions of use and maintenance of the machine as set out in this manual are not adhered to, the guarantee will be immediately lifted and no longer applicable.
UK-364727 AA - 1209
5
