SECTION 7 – SERVICE
7.11
FINGER BAR IDLER ARM REMOVAL/INSTALLATION
D00039
1. 2. 3. 4.
Finger Bar Finger Bar Belt 5/16 x 1 Bolt 5/16 Lock Washer
5. 6. 7. 8.
3/8 Washer Finger Bar Idler Arm Idler End Rotor Idler Rotor Seal Plate
9. 3/8x3/4 Bolt 10. 3/8 Lock Washer 11. 3/8 Flat Washer
WARNING: Always use heat protective gloves to prevent burning your hands when handling hot materials. Remove all combustible materials from the vicinity of an open flame. Have a fire extinguisher nearby.
Special Tools Required: •
Torch
