SECTION 7 – SERVICE f) Proceed to extract the bolts one revolution at a time until the motor is removed. g) Remove the two flange head bolts and place aside. h) Remove the two 1/4" hex head bolts and thread them into the previously removed flange head boltholes until they contact the hub. P00386
i) Rotate each bolt one revolution at a time until the hub releases.
Mounted Header Brace
j) Remove the coupler and hub and / or pulley.
7.2 HYDRAULIC SYSTEM
Installation: a) Install the coupler with hub or pulley onto the roller shaft. Be sure the coupler bottoms out with the end of the roller shaft.
CAUTION: High-pressure hydraulic oil can cause serious injuries such as burns, cuts, and tissue damage! Always take precautions when working with hydraulic oil. Wear safety goggles, gloves and thick clothing. Seek immediate medical attention if cut or burnt.
b) Lock into place with the 1/4" bolts and lock washers. When tightening the 1/4" bolts, alternate several times from one bolt to the other, until both bolts are equally secure. Return the 1/4" flange head bolts to their original location.
A) Hydraulic Motor Installation/Removal
c) Install the hydraulic motor with key into the hydraulic motor coupler and lock into place with the setscrews.
Removal: a) Lower the pickup to the ground shut off combine and remove key. b) Remove the two hydraulic lines from the motor if the motor is being replaced or repaired. Use a bucket to catch escaping oil. c) Remove all shields that will interfere with this procedure. d) Loosen the setscrew on the motor coupler. e) Extract the two flange head bolts until they contact the motor.
P00209
Hydraulic Motor & Torque Arm (MEGA)
37
