Safety rules
Safety rules SAFETY PROP DANGER! Carry out all work under the raised maize picker or feeder housing only after having propped it safely. – Position safety prop (1)! 1 1
Raise the feeder housing to the highest position. Loosen safety prop (1) and swing it onto the hydraulic piston. (Fig. 1)
SAFETY DECALS WITH PICTORIALS Safety decals are attached to the danger zones of the machine. These safety decals help to alert persons to hazards which can cause personal injury. The pictorials provide instructions to avoid the hazard. These safety signs, their placement on the machine and a brief explanatory text are shown on the following pages. The CLAAS part number of every decal is stated ahead of the text. The figure in ( ) refers to the adjacent picture and indicates the correct location of the decal on the machine. Safety decals that are damaged or cannot be recognised any more must be replaced immediately by new ones. When parts that have decals are replaced, always make sure to install the relevant new decals with each new part.
0298 345.5 - ABA/BA CONSPEED 12 / 8 / 6
4.3
