4 Feed rake conveyor 4.1 Feed rake conveyor 10117 31862
4.1.18 Top shaft, exploded view (three-part feed rake slat)
11658
1 2 3 4 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
000 293 109 0 - RHB LEXION 600 - 570 - 01/07
103
Set screw Cam wheel Bearing shell Friction bearing 110 x 115 x 50 Lock collar Bearing assembly Bushing Top shaft Sprocket Gib head key Set screw M10 x 1.25 x 8 DIN 916 Lock collar Bearing assembly, mounted Adjusting washer Contact washer A12 DIN 201 Hex. bolt ISO 4017-M12 x 30-8.8 Hex. bolt ISO 4017-M10 x 35-8.8 Feed rake slat Feed rake chain Chain link with shackle Chain link (inside) Chain link (cranked)
161
