CLAAS JAGUAR 900 – 830 JAGUAR 900 – 830 Profistar JAGUAR 900 – 830 Speedstar Repair Manual

Air conditioning Unlock the hose (A) on the radiator cage and pull off.

Hinge up the radiator cage.

A

(Fig. 36)

36 Unscrew the hose lines (B) from the condenser (C) and close off on both sides with plugs.

Unscrew the condenser (C) from the radiator cage.

(Fig. 37) B

C

37

Fitting the condenser 1. Screw the condenser (C) to the radiator cage.

B

2. Screw the hose lines (B) to the condenser (C) using new round seal rings. When doing this, observe the relevant tightening torque – see page 1.4.3, Tightening torques hydraulic fittings.

C

(Fig. 38)

38 3. Push the hose (A) onto the spigot on the radiator cage (C) and lock.

A

(Fig. 39)

39

0298 826.1 - RHB JAGUAR 900 – 830 Profistar / Speedstar

2.3.13
