Service and Repair Manual Type / Description: Drawing no. : Valid as of Serial no. : Date : Author
CL 16 Planetary-steering axle in CLAAS SFM Grassland machine LAP 7501.102 01 26.01.2007 Rauh
1.5.2.4 Checking oil level Note: Clean the area around the screw plugs of dirt beforehand. • Differential Remove oil fill plug (No.40), the oil level must reaches to the bottom edge of the thread opening (No.40), if need refill oil corresponding to the Lubrication Table. Check the level approx. 5 minutes. Tightening moment for the oil fill plug (No.40) is 80+10 Nm. (Fig. 1). • Planetary-Drive First of all, turn the wheel hub until the oil control plug (No.50) is perpendicular to the horizontal position of the hub (Fig. 4 / Position 2). Remove oil control plugs (No.50) the oil level must reaches to the bottom edge of the thread opening (No.50), if need refill oil corresponding to the Lubrication Table. Check the level approx. 5 minutes. Tightening moment for the oil control plugs (No.50) is 50+5 Nm. (see Fig. 4 / Position 2)
1.5.2.5 Inspection • Various visible bolts and nuts Due to stresses and vibrations exerted, it is possible for various bolts and nuts to set or give way. Timely tightening of these will prevent any leaks or other greater damages. • Wheel Nuts Due to stresses of vehicle motion, the wheel nuts may set or loosen. Timely tightening will prevent a deflection of the centre to the rim. Tightening moment for wheel nuts is 550 Nm. • Wearing test for Multi-Disk Operating Brake (see Fig. 13 / Page 25) Check disk set, if need replace disk set, then see Repair Manual − Therefore turn the wheel hubs until the rest oil drain plugs (No.52*) are positioned on top. (above the oil level). − Apply the brake and remove rest oil drain plugs (No.52) − Measured in applied position. − Measure with a feeler gauge from the sureface for plug (No.52) to the test nib of the 3th disk. (nominal size for new disks 50.5 + 0.9 / -0.4 mm) (wearing size for wear out disks 47.5 - 0.8 mm
9
