“Hexashift” Key 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33
Clutch bearing. Ball bearing with sealed side. Locking ring. Blanking plate. Screw. Screw. Additional multiplier cover. Screw. Friction washer. Clutch “D” housing. Belleville washer. Brake “C” discs. Clutch, brake “D”, “C” bearing plate. Brake “C” backplate. Clutch “D” discs. Clutch “D” backplates. Spring. Clutch, brake “D”, “C” piston. O-rings. Cover. Screw. Clutch “D” splined hub. Second epicyclic gear set sun gear. Screw. Spring washer. Locking ring. Ball bearing. Lubricating oil deflector. Second epicyclic gear set planet carrier. Second epicyclic gear set planet gear. Screw. Second epicyclic gear set ring gear. Lubrication ring.
34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66
Ball bearing. Locking ring. First epicyclic gear set sun gear. Screw. First epicyclic gear set planet carrier. First epicyclic gear set planet gear. Retaining ring. Retaining ring. First epicyclic gear set ring gear. Ball bearing. Spring washer. Screw. Ring gear holder. Locating pin. Additional multiplier housing. Locating pin. O-rings. Clutch, brake “A”,“B” piston. Spring. Clutch “B” splined hub. Shaft. Clutch “B” discs. Clutch “B” backplates. Brake “A” discs. Brake “A” backplate. Clutch, brake “B”,“A” bearing plate. Belleville washer. Clutch “B” housing. Friction washer. Washer. O-ring. O-ring. Multiplier housing.
Arion 640-510 – 01.2009 – GB
67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97
Screw. Screw. Ball bearing. Third epicyclic gear set ring gear. Bronze bush. Ball bearing. Third epicyclic gear set planet carrier. Third epicyclic gear set planet gear. Third epicyclic gear set sun gear. Locking ring. Screw. Cover. Shaft. O-ring. Clutch, brake “F”,“E” piston. Spring. Clutch “F” discs. Clutch “F” backplates. Brake “E” discs. Brake “E” backplate. Clutch, brake “F”,“E” bearing plate. Belleville washers. Ball bearing. Clutch “F” housing. Friction washer. Washer. O-ring. Multiplier cover. Screw. Lip seal. Triple spring washer.
B2.3
