Hydraulic part of the lubrication Checking the lubrication pressure and flow of the service brakes (after valve) Test conditions: – Oil temperature at 60°C. – Engine at 2 300 rpm. – Transmission engaged (tractor made safe on stands). – No actuator activated (spool valves, steeering, PTO, etc.).
HYDRO TESTER
395msm88
Fig. 9
• Fit the flowmeter and pressure sensors of kit Nr.00 0178 310 0 and 00 0178 320 0. • Connect the portable command of kit Nr.00 0178 310 0 on the pressure and flow rate sensors. The values measured must be: – 13 l/min and 1,5 bars for a 60 l/min circuit
C1.10
Arion 630-610 C – 1.2009 – GB
