C-2 PICKUP HEADER MODEL PH13
49
SWATHMASTER ATTACHMENT
HYDRAULIC HOLDDOWN
ITEM 1 2 3
4 5 6 7 8 9 11 12 13 14 15 16 17 18 19 20 21 22
NUMBER QTY
DESCRIPTION
71392133 71392472 71392474
2 2 1
71400808
1
71392157
1
71392303 70921973 71392542 71392543 71392446 71392134 71392547 71392135 71392136 70917377 71392137 71392138 71392139 71400809 70921332 70918268 71392492 70917356 70917372
2 2 6 2 2 2 2 AR 5 AR AR 1 1 8 AR 8 4 AR AR
HOSE, HYD., FLEX-POINT ELBOW, #6 MORB X #6 MJIC *CYLINDER, HYD. 1-1/2" BORE X 10" STROKE (MASTER) *CYLINDER, HYD. 1-1/2" BORE X 10" STROKE (MASTER) 3000 PSI *CYLINDER, HYD. 1-1/4" BORE X 10" STROKE (SLAVE ) 3000PSI BRACE, CYLINDER (FOR SHIPPING ONLY) BOLT, 3/8" X 2-3/4" UNC WASHER, FLAT 3/8" WASHER, NEOPRENE 3/8" X 1.1 X .062 LOCK, SAFETY NUT, UNITORQUE 3/8" SCREW, SHEET METAL #14 - 3/4" CLAMP, HYD. HOSE, 9/16 CLAMP, DRILLED, 3/8" PIPE WASHER, FLAT, 5/16 BOLT, 5/16-18 X 2.0 LINE, STEEL, HYD. LIFT, 12 FT. LINE, STEEL, HYD. LIFT, 14 FT. WASHER, .625 X .781 X .188 BOLT, 5/16" X 3/4" UNC WASHER, FLAT 5/8" SAE PIN, HITCH 1/8 WASHER, LOCK, 5/16 NUT, 5/16 *NOTE: 3000PSI CYLINDER HAS #3 STAMPED IN CYLINDER SHAFT END. 1500PSI CYLINDER NOT STAMPED D00150A PR: 44
