A-10 PICKUP HEADER MODEL PH13
9
FRAME
TABLE ASSEMBLY
ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 -
NUMBER QTY
DESCRIPTION
71392420 71393769 71393770 71392425 71392393 71392392 71392405 71392388 71392387 71392389 71392390 71392391 71392511 71393771 71392124 71392410 71392431 71392101 71392560 71392563 71392565 71392564 71392575 70921960 71392116 1102797 390972X1 70918266 70950230 Y705269 1177981 1102801 70950995 71392582 71392114 71393772 71392561 70950984 71392584 71400785
FRAME, HEADER W/DECALS PANEL, HEADER LH PANEL, HEADER RH (NOT SHOWN) PLATE, SKID BAR, STRIPPER LH BAR, STRIPPER RH (NOT SHOWN) BAR, STRIPPER UPPER LEVER, SHIELD LOCKING LH LEVER, SHIELD LOCKING RH (NOT SHOWN) SPRING, LOCKING LEVER RH (NOT SHOWN) SPRING, LOCKING LEVER LH HINGE, SHIELD LOCK, ROTARY LH LOCK, ROTARY RH SHEET, BOTTOM HEADER REPAIR PLATE, HOSE CLAMP STAND, HEADER BUMPER, RUBBER BOLT, CARRIAGE M6 X 1 X 20MM BOLT, CARRIAGE M8 X 1.25 X 20MM BOLT, CARRIAGE M8 X 1.25 X 25MM BOLT, HEX M8 X 1.25 X 20MM BOLT, M12 X 1.75 X 25MM SCREW, HEX HEAD 1/4-20 UNC X1 PIN, 3/8 X 2-1/4 LOCK WASHER, LOCK 6MM WASHER, FLAT 8MM WASHER, FLAT 10MM WASHER, FLAT 12MM WASHER, LOCK 6MM WASHER, LOCK 8MM (13FT) WASHER, LOCK 12MM NUT, M6 X 1 NUT, M8 X 1.25 (13FT) BRACKET, DRIVE SHAFT STORAGE CAP, PLUG STORAGE CAPSCREW, M6 X 1 X 16MM NUT, NYLOCK M6 NUT, M12 *PLATE, LATCH POCKET REPAIR, 1.5(38.1MM) X 2(51MM) X 5/16(7.9MM)
1 1 1 2 1 1 2 1 1 1 1 4 1 1 1 1 2 4 8 10 10 3 4 2 2 14 23 2 4 8 23 4 8 22 1 1 2 2 2 3
*NOTE: FOR HEADERS WITH MISALIGNMENT OF COMPONENTS EFFECTIVE S/N SN41101-SN41173 EXCLUDING S/N SN41125/41128-30/41161-63 D00442 PR: 8
