C-8 PH13/PH15 PICKUP HEADERS
55
RAKE-UP ATTACHMENT
DRIVE END ROTOR
ITEM
NUMBER QTY
DESCRIPTION
1
71392333
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
71392555 71392266 71392222 71392552 71392265 70921969 70950220 70923518 70920439 71392213 71392457 70922471 1102801 71392214 70918267 71392458 71392261 71392329
DRIVE ASY., ROTOR (INCLUDES:DRIVE ROTOR AND BEARINGS) BUSHING,#8 MACHINERY,1/4"THK(1/GEARBOX) KEY, 1/4 X 1/4 X 13/16 GEARBOX, SMALL (COMPLETE) PLUG, BRASS, 1/8 NF KEY, 1/4 X 1/4 X 1-1/4 BOLT, 3/8 X 1-1/2 UNC LOCKWASHER, M10 NUT, 3/8 UNC NUT, JAM 7/8" UNF ARM, FINGER BAR DRIVE (MIRROR) BEARING, 6205 LLC NUT, 7/16 UNF LOCKWASHER, M12 ARM, FOLLOWER (MIRROR) WASHER, FLAT, 7/16 BEARING, 6202-16 DDU SHOULDER BOLT BOLT ASY., SHOULDER (INCLUDES: SHOULDER BOLT, BEARINGS AND HARDWARE)
6 6 6 12 6 12 6 12 12 6 12 6 6 6 6 12 6 6
NOTE: COMPLETE DRIVE END ASSEMBLY (INCLUDES: SCROLL PLATE, DRIVE ROTOR, MAIN GEARBOX, SMALL GEARBOXES, DRIVE FINGER BAR ARMS, FOLLOWER ARMS AND BEARINGS, ETC.) (SERVICE W/#71392592) D00023 PR: t05h23i05d0022
