BACKUP PANEL
BACKUP PANEL INSTALLATION 219-8023
The Backup Panel provides secondary (backup) vessel operator control of the powertrain (engine and transmission). The Backup Panel has a protected operator input switch for transferring vessel control from the primary operator controls to the secondary (backup) operator control panel. The Backup Panel provides engine throttle control and transmission gear control via a proprietary CAN data link to the Backup System Processor. The backup panel (for a twin engine installation) consists of a single backup enable switch, a station active button, an active lamp, and two throttle/gear controls.
! WARNING When using the gear lockout feature with the backup panel, be sure that both throttle/gear levers are moved into the forward position. If only one lever is moved into the forward position, then the opposing gear will engage.
F
F
R
R
N
N
F
F
R
R
N
N
Multi-Station Control Installation Guide
43
