COOLING SYSTEM 144-6081 PUMP GP-AUXILIARY SEA WATER S/N: JTS135-UP AN ATTACHMENT
SMCS-1371 NOTE
REF NO
i03513189 GRAPHIC REF
PART NAME PART NUMBER
1 1 143-9207 2 1 143-9208 3 1 0S-1566 4 1 5P-8247 CY 5 1 318-2579 6 1 9X-7371 7 1 8T-6766 8 1 144-6074 9 1 144-6076 10 1 0S-1590 11 1 5M-2894 12 1 9S-8752 B 13 1 0S-1571 14 1 5N-1845 15 1 2N-0822 16 1 3P-6061 B 17 1 3P-6061 18 1 6L-2280 18A 1 233-8525 M 19 1 8T-4192 20 1 7X-0584 21 1 5L-5879 22 1 5B-3265 23 1 9B-0887 B-USE AS REQUIRED C-CHANGE FROM PREVIOUS TYPE M-METRIC PART Y-SEPARATE ILLUSTRATION
196
COOLING SYSTEM
QTY
1 1 4 4 1 1 2 1 1 8 16 8 8 2 2 2 2 1 1 4 8 2 2 1
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
ELBOW ELBOW BOLT (5/8-11X1.5-IN) WASHER-HARD (17X32X3.5-MM THK) PUMP GP-AUXILIARY SEA WATER SEAL-O-RING PLUG-PIPE GASKET GASKET BOLT (3/8-16X2-IN) WASHER-HARD (10.2X18.5X2.5-MM THK) NUT-FULL (3/8-16-THD) BOLT (3/8-16X1.75-IN) FLANGE PLATE GASKET GASKET ROD-ZINC (AUXILIARY SEA WATER PUMP) PLUG-PIPE BOLT (M12X1.75X25-MM) WASHER-HARD (13.5X20.5X2-MM THK) ADAPTER GASKET PLUG-PIPE
1 of 2
208
SEBP4550-06
