OPERATING TECHNIQUES
104
◆ Incorrect Operating Steps and Blinking of the Mast Interlock Indicator Lamp NOTICE: The mast interlock indicator lamp will blink when you sit on the operator's seat while the lift or tilt lever is placed to the operating position. To clear this function, move the lift or tilt lever to the neutral position.
Example 1
K00011
In the following three examples, the mast interlock indicator lamp blinks and the mast and attachment would not move (FC model) / the mast would not move (MC model) even though the operating levers are in the operating position. This is not a fault but the function of the interlock system. In this case, follow each instruction in "What to Do." NOTICE: The mast interlock will work only for the lift and tilt levers. Attachments can be moved regardless of whether the mast interlock function is operating or not. Therefore, when the attachment lever is operated, some of the attachments will move, even though the engine is not running or the key switch is in the (OFF) position, as a result of the handling load or of its own weight.
104
K00012
DON'T The mast interlock indicator lamp will blink when the key switch is in the (ON) position and you are not properly sitting in the operator's seat.
K00013
What to Do Sit securely. This causes the mast interlock indicator lamp to go OUT and you can operate the lift or tilt lever.
