SYSTEM ADJUSTMENTS 3.2 Diagnostic Screen Layout: Diagnostic "D" Codes Screen
Data Stream: Length of Data Stream: Com Port: Program Version: Map Version: Check Engine Codes:
Must be scrolling for proper connection to ECU Typically 91 bytes Shows Com Port selected from pull-down menu Indicates EPROM installed in ECU Indicates ECU calibration NONE - No check engine codes BAT Battery Voltage Error CHRG - Charging System Error ETMP Engine Block Temperature Sensor Error HTMP - High Engine Block Temperature KILL Emergency Engine Shutdown Activated MAP Manifold Absolute Pressure signal Error OXY Oxygen Sensor Error/Fuel System Error THRPedal Sensor out of Range/Open Circuit TRIG TACH Signal Error
