10. Cab (1) A cab has been designed to achieve a quieter operator’s compartment. (2) The cab is equipped with a heater. (3) The cab’s three windows (front, rear and roof windows) are equipped with wipers. (4) The cab can be equipped with optional rear working lamp and strobe lamp. (5) The cab can be removed in the following procedure. • Disconnect the lighting system wiring wherever appropriate. • Attach slings to the four hanger brackets on the cab roof, then attach the slings onto the hoist. (Do not lift the cab at this stage.) • Remove the four cab mounting bolts B. • Lift the cab. When installing the cab, follow the removal procedure in reverse. (6) The cab weighs approximately 300 kg (660 lbs).
208997
– 10 –
