3500 ENGINES
DISASSEMBLY AND ASSEMBLY REAR GEAR GROUP
REMOVE REAR GEAR GROUP Tools Needed 1P520 Driver Group
1212-11 A 1
start by: a) remove flywheel housing
NOTE: Before the flywheel housing is removed, the 3508 engine must be put in time to make sure the rear gear group is in alignment according to the rotation of the engine as shown.
1.
Remove plate (1) to remove gear assembly (2) from the shaft.
2.
Use tool group (A) and a press to remove bearing (3) from gear assembly (2).
3.
Use tool group (A) and a press to make a separation of the gears for gear assembly (2).
4.
Remove the bolts to remove the shafts, gears (4) and the washers from the cylinder block.
387
