AIR INLET AND EXHAUST SYSTEM 297-7745 MUFFLER GP S/N: GDC1874-UP PART OF 287-0120 ENGINE AR
SMCS-1062 NOTE
REF NO
1 2 3 4 5 M 6 7 8 M 9 10 11 M-METRIC PART
SEBP5476
i03503182 GRAPHIC REF
1 1 1 1 1 1 1 1 1 1 1
1 of 2
PART NAME PART NUMBER
297-7791 266-6321 266-6319 266-6320 297-7654 6V-8231 5I-8040 5I-7679 178-6554 5I-7633 094-7583
QTY
1 2 1 1 4 8 1 1 3 6 1
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
MUFFLER U-BOLT BRACKET BRACKET BOLT (M10X1.5X37-MM) NUT (M10X1.25-THD) PIPE GASKET STUD (M10X1.5X15-MM, M10X1.25X20-MM) NUT (M10X1.25-THD) CLAMP AS
AIR INLET AND EXHAUST SYSTEM
109
