COOLING SYSTEM 296-4655 PUMP GP-WATER
S/N: GDC1874-UP PART OF 279-7865, 287-0120 ENGINE AR SMCS-1361 NOTE
SEBP5476
i02618456
REF NO
GRAPHIC REF
1 1A 1B 1C 1D 1E 1F 1G 1H 1J 2 3
1 1 1 1 1 1 1 1 1 1 1 1
1 of 2
PART NAME PART NUMBER
178-6633 5I-7696 178-6635 8T-9598 5L-6326 178-6634 5I-7697 2H-3814 125-2947 178-6636 294-1738 8T-4121
QTY
1 1 1 1 1 1 1 1 1 1 7 4
1
2
3
4
5
6
(PRODUCT LEVEL)
SEE PAGE
PUMP GP-WATER FLANGE SHAFT RING-RETAINING BALL BEARING (62-MM OD) IMPELLER SPACER (28-MM) BALL BEARING (52-MM OD) WASHER (1-MM THK) SEAL BOLT WASHER-HARD (11X21X2.5-MM THK)
COOLING SYSTEM
75
