HYDRAULIC SYSTEM 242-6487 LINES GP-AUXILIARY HYDRAULIC– STICK, HIGH PRESSURE
S/N: WNE1-UP; ZMF1-UP; CWG1-UP 2.92-M (9.6-FT) PART OF 338-9838, 338-9839, 338-9840, 338-9841, 347-9940 OPTION AR-LINKAGE AN ATTACHMENT SMCS-5057 NOTE
REF NO
i02475649 GRAPHIC REF
I
PART NAME PART NUMBER
QTY
1 1 5I-8510 1 2 1 173-7916 4 I 3 1 253-6445 1 4 1 253-6453 1 5 1 253-6454 1 CY 6 1 277-0954 2 7 1 1P-3703 3 8 1 1P-3704 3 9 1 1P-5767 4 10 1 6V-0400 4 11 1 7Y-4538 4 12 1 8T-4121 4 M 13 1 8T-4139 8 M 14 1 8T-4183 4 M 15 1 8T-4184 8 M 16 1 8T-4194 8 17 1 8T-4223 24 M 18 1 8T-4956 4 M 19 1 8T-6685 4 C-CHANGE FROM PREVIOUS TYPE I-REFER TO HYDRAULIC INFORMATION SYSTEM M-METRIC PART Y-SEPARATE ILLUSTRATION
558
HYDRAULIC SYSTEM
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
HOSE AS CLAMP-HALF HOSE AS TUBE AS TUBE AS VALVE GP-MANUAL (AUXILIARY, SHUTOFF) SEAL-RECTANGULAR SEAL-RECTANGULAR FLANGE-HALF FLANGE-HALF CLAMP-HALF WASHER-HARD (11X21X2.5-MM THK) BOLT (M12X1.75X30-MM) BOLT (M12X1.75X40-MM) BOLT (M12X1.75X45-MM) BOLT (M12X1.75X50-MM) WASHER-HARD (13.5X25.5X3-MM THK) BOLT (M12X1.75X35-MM) BOLT (M10X1.5X110-MM)
1 of 2
851
SEBP5476
