HYDRAULIC SYSTEM 248-9825 LINES GP-PILOT (contd. ) NOTE
REF NO
GRAPHIC REF
29
1,2
PART NUMBER
164-5628
QTY
3
1,2 3J-1907 1 1,2 6V-8397 1 1,2 107-6631 1 30 1,2 8T-4121 20 M 31 1 8T-4136 4 M 32 1,2 8T-4137 15 M 33 2 8T-4198 2 34 2 289-5657 1 35 2 4P-7581 1 C-CHANGE FROM PREVIOUS TYPE I-REFER TO HYDRAULIC INFORMATION SYSTEM M-METRIC PART Y-SEPARATE ILLUSTRATION
656
HYDRAULIC SYSTEM
i03630856
PART NAME 1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
CONNECTOR AS (EACH INCLUDES) SEAL-O-RING SEAL-O-RING CONNECTOR-FILTER WASHER-HARD (11X21X2.5-MM THK) BOLT (M10X1.5X25-MM) BOLT (M10X1.5X20-MM) BOLT (M10X1.5X100-MM) HOSE AS CLIP
