126 Maintenance Section
31200245
7. Install new seals on screw and glass bowl. 8. Align glass bowl to canister and install screw. Torque to 5 Nm (44 lb-in).
Note: Before the machine is refueled or before the fuel filler cap is cleaned, remove foreign material from the top of the fuel tank.
9. Replace secondary fuel filter. 1. In order to open protection cover (3), unlock lock (2) and turn lock (4) counterclockwise. Then, pull latch (1) outward.
Secondary Filter
5
OAL1330
1. Place suitable container under fuel filter. 2. Clean outside of filter and remove canister (5). 3. Install new canister and tighten by hand. 4. Prime the fuel system. Refer to Operation and Maintenance Manual, "Fuel System - Prime" for further instructions. Illustration 234
5. Start the engine and check for leaks.
g01204058
2. Locate fuel filler cap (6) and remove the padlock, if equipped.
Fuel Tank Cap - Clean
3. Lift latch (5) and turn the fuel filler cap counterclockwise. This will release the fuel filler cap. 4. Remove fuel filler cap (6) and inspect the fuel filler cap. Replace the fuel filler cap if the fuel filler cap is damaged. 5. Install the fuel filler cap. 6. Install the padlock, if equipped. 7. Close the protection cover.
Illustration 233
g01202853
The fuel filler cap is located behind protection cover (3) on the left side of the cab.
