Bidirectional Cutting Cycle – Step 7 – Shearer in HG
Restrictions SRB is not subject to the standard restrictions; however, the actions that SRB triggers are subject to the restrictions defined for each type of action. SRB cannot be initiated and will abort (err: "SRB FACE AUTOMATION aborted") for a Quickstop and for an Incomplete Network.
Parameter Summary Infrared Tracking To run Inrared tracking, change this value to On. If Serial or Manual are selected it will change this option to off. Manual Tracking To run Manual tracking, change this value to On. If Infrared or Manual are selected it will change this option to off. Beginning Shield 1-30 First shield on face that SRB will control. Ending Shield from TG 1-30 Number of shields from TG that marks last shield that SRB will include. (1 means last shield; 2 means next to last shield, etc.) H->T Asq All, None Toggle ASQ options for head-to-tail pass. H->T Push Mode All, None Toggle push options for head-to-tail pass. H->T Push Trig Shld 1-310 Begin pushing when shearer reaches this shield. Set high to delay push. H->T Push Reverse On, Off Reverse the push once the shearer reaches the Trig Shield and follow normally from that point; most useful when H->T Trig Shld is set high. H>T Push Protection Full, None Set level of conveyor protection during SRB push for H->T pass. © Caterpillar
66
