DISPLAY GLOSSARY
:Default Displays: Following are the displays that can appear on the PMC-R as the default in different situations. #123 Shearer Zone Default display: this shield is in the shearer safety zone #123 -Wedge Advance Default display: shield is in wedge advance group #123 -Tapered Push Default display: shield is in tapered push group #123 -Wedge -Taper Default display: shield is in wedge advance group and in tapered push group #123 BTP Lockout Btp Control lock button is pressed.; no push allowed on these shields. #123 SYSTEM TRIPPED! Default display: system is tripped; to reset system, press Start key and then P key. #123 Network! SRV-150 Default display: network is broken - communications is successful over range shown. Probably caused by broken shield to shield cable or network params are set wrong. #123 No Net Number Default display: SCU has no network number due to invalid parameter settings in Configuration->Network section or due to faulty cabling. Can be numbered manually using D-Enter. #123 No Network Network is not correctly established. Check network parameters in Configuration>Network section. SRVR BTP Station Lost Unrecognized signal from Belt Tailpiece Control. #123 < ULOCK 4 More © Caterpillar
132
