BMA Shield PMC-R Operating Manual
Random TCC A TCC Random group can only be selected via adjacent control. In the example below an operator has requested a random TCC group operation.
TCC: RAND
10 > 16
r100 c100 s100
SA-Idle
The parameter setting for ‘TCC at once’ in the TCC parameters is set to 4 in this example. The ‘TCC group’ parameter is set to 7 in this example.
1 0
1 1
1 2
1 3
1 4
1 5
1 6
1
2
1
2
3
4
3
An example of the sequence that the shield TCC’s are executed is shown above. A 4 shield (TCC at once) group initiate. Shield 10 and 12 begin there TCC’s at the same time. Once shield 10 and 12 have both completed there TCC’s shields 11 and 13 begin there TCC’s. On completion of the 4 shield group the next group of 3 begin their initialise. The 4 shield group sequence described is only an example of what may occur. As the Random Mode has been selected the sequence may also occur as below with these settings.
1 0
1 1
1 2
1 3
1 4
1 5
1 6
2
1
2
1
4
3
4
NOTICE It is not possible to select Random mode for fromto operations.
EM027362-01
Page 59 of 74
