BMA Shield PMC-R Operating Manual
Initiate in–shield auto TCC WARNING Mine safety procedures in regards to shield movement MUST be observed.
This feature allows the operator to trigger an automatic TCC sequence in the PMCR’s local shield. The sequence will operate according to the TCC parameters. Providing the default remote distance is set to 0. 1.
Press
2.
Pressing
Press the on the face.
twice.
will start the in-shield TCC automatic sequence.
key to stop the TCC at anytime. This will stop all automatic functions
Press the key and then automatic functions in other shields.
to stop TCC’s in the shields without stopping
NOTICE When using the STOP key to stop a TCC group any shields that are currently performing a TCC will park its caving shield and slide first.
EM027362-01
Page 53 of 74
