BMA Shield PMC-R Operating Manual
Initiate a lock on rear AFC advance WARNING Mine safety procedures in regards to shield movement MUST be observed.
If a lock on push is initiated in a Shield the Rear Conveyor ram will pull the Rear AFC until the ram stroke meets the target ‘RCP LockOnP. Ext’ or until the ‘RCP LockOnP.tmo’ timer expires.
1.
Press
RCP LockOnPull OFF ON r100 c100 s100
SA-Idle
The default display will prompt the operator to activate the lock on pull.
2.
Press
to activate the lock on pull.
3.
Press
to turn off the lock on pull.
Press
to stop the Lock on pull at anytime.
NOTICE During a lock on pull all ram stroke protection may be disabled. Use of lock on pull can result in damage to the equipment.
EM027362-01
Page 49 of 74
