BMA Shield PMC-R Operating Manual
Initiate an adjacent group conveyor pullback WARNING Mine safety procedures in regards to shield movement MUST be observed.
1.
Press
to select Conveyor Pullback Operation.
2.
Select the side you want the function to operate with the
or
key.
Direction Target Extension
CP:
0 36
<
r2
c100 s100
17 SA-Idle
The display shows Conveyor Pullback will start at Shield 17 and work towards Shield 17 and stroke will be 0% after Pull Back.
3.
Pressing will operate.
, the operator can toggle between the directions that the group function
4.
Press
to begin the conveyor pullback.
Press
to stop the Conveyor Pullback at anytime.
NOTICE Global parameters in the conveyor pullback menu determine the adjacent group size ‘CP group’ and the target extension ‘CP extens’. These are configurable under Level 1 password control.
