BMA Shield PMC-R Operating Manual
Initiate an adjacent group bankpush WARNING Mine safety procedures in regards to shield movement MUST be observed.
1.
Press
.
2.
Select on which side of the local Shield to operate the bankpush by pressing either or
.
Operating mode
BP: SNAKE r2 3.
Pressing TAPER).
Direction
61
>
c100 s100
SA-Idle
, the operator can toggle between the operating modes (ALL, SNAKE,
All =all Shields will push until it reaches the target stroke. Snake = The AFC will push to form a snake. Taper = AFC will push over with an evenly calculated Taper between the Shields in the display. 4.
Pressing will operate.
, the operator can toggle between the directions that the group function
NOTICE The default direction assumes that when snake mode is selected the operator wishes to bring the snake towards him.
5.
Press
to begin the AFC advance.
The Shields will push the AFC in the group range to the target stroke.
Press
EM027362-01
to stop the bankpush anytime.
Page 40 of 74
