BMA Shield PMC-R Operating Manual
Initiate an SRB Newstart – manual mode The manual mode is only used, if the shearer data is lost due to a fault. The manual SRB mode can be started the same way as the serial mode. 1.
Switching from SHEARER COMMUNICATIONS to MANUAL tracking is achieved by accessing the SRB PARAMETERS menu, and using the ‘L’ or ‘M’ keys to change the display to S track once the relevant password has been entered.
S track
S_MG
r2
SA-Idle
c100 s100
2.
Using the ‘P’ key will change display to either ‘NONE’, ‘S_MG’, or ‘MANUAL”.
3.
Press
and then select shearer direction by pressing either
4.
Press
to activate SRB.
5.
In ‘Manual’ mode, the shearer position is now updated manually to the PMC-R system by the shearer operator. The
or
key will flash in the shields adjacent to the Main
Gate drum where an update of the shearer position is possible by pressing then the 6.
.
and
key.
To stop SRB press
WARNING It is extremely important that the operator constantly updates the machine position to ensure collision between the Shearer and Shields do not occur.
EM027362-01
Page 34 of 74
