Figure 21: Mode control position warning; located by dozer-blade control.
Figure 22: Lower loads before switching to dozer mode warning; located on winch control box.
C)
DOZER MODE—WINCH CONTROLS LOCKED: Before switching to dozer mode, lower any suspended load to the ground. NO LOAD IS TO BE SUPPORTED OR CARRIED BY THE SIDEBOOM IN DOZER MODE. Move the lever to this position to operate the unit as a bulldozer. The winch controls do not function, and the equalizer lockout cylinders are retracted. The blade controls function at full speed.
Hook Control Lever
Figure 23: Hook control positions.
A)
HOLD: The lever self centres to this position whenever it is released. In this position, the load winch brake will set, and the hook will stop and remain at the position it is in.
033-08OP-003B
S/N D5H0021 - UP S/N D6M0021 - UP S/N D6N0021 - UP
13
