OPERATING INSTRUCTIONS RH120E Operation Positioning of the machines
Emergency travel
The auxiliary machine is driven close to the RH120E from behind (Fig. 2-99:).
Start up the engine of the auxiliary machine. The brakes of the RH120E are released by travel pressure.
Loosen the high-pressure lines (1, 2, 3 and 4, Fig. 2-100) and close the open ends of the hoses. Connect the hoses from the auxiliary machine to the ports of the "travel hydraulics" of the excavator.
Initiate the travelling movements carefully with the control levers. Adjust the direction and travelling speed of both tracks accordingly.
High-pressure hoses (1 and 2) - circuit 1 on auxiliary machine
Shift the control lever to the final position. Make sure the auxiliary machine is able to "follow"
High-pressure hoses (3 and 4) - circuit 2 on auxiliary machine
The RH120E can be steered as usual by releasing the one or the other control lever briefly. Drive the excavator out of the hazard zone only.
Fig. 2-100 :
