OPERATING INSTRUCTIONS RH120E Operation Assemblies resp. Measuring device reservoirs
Remarks
Pump transfer gearbox
Dipstick (1, Fig. 2-64:)
Stop filling when the oil reaches the "max" mark on the dipstick (see Part 3, chapter "Pump transfer gearbox Checking the gearbox oil level/Filling in oil").
Engine
Dipstick (1, Fig. 2-65:)
Stop filling when the oil reaches the "max" mark on the dipstick (see chapter "Engine - engine oil level/filling in oil").
Engine oil tank
Dipstick (2, Fig. 2-66:)
Stop filling when the oil reaches the "max" mark on the dipstick (see chapter "Engine - oil tank Checking the oil level in the engine oil tank/Filling in oil").
Fig. 2-64:
Fig. 2-66:
Fig. 2-65:
2-58
BA RH120E(3 725 023.00)-EN
