OPERATING INSTRUCTIONS RH120E Operation Fig. 2-56: (optional) No.

Element

Function

191 Underpressure gauge

Air filter (left engine 1, outside)

Indicates the underpressure in the air filter.

Underpressure must be less than 635 mm water column.

192 Underpressure gauge

Air filter (left engine 1, inside)

Indicates the underpressure in the air filter.

Underpressure must be less than 635 mm water column.

193 Underpressure gauge

Air filter (left engine 2, inside)

Indicates the underpressure in the air filter.

Underpressure must be less than 635 mm water column.

194 Underpressure gauge

Air filter (left engine 2, outside)

Indicates the underpressure in the air filter.

Underpressure must be less than 635 mm water column.
