OPERATING INSTRUCTIONS RH120E Operation Fire extinguisher The excavator is equipped with two fire extinguishers (arrow, Fig. 2-25:).
Handling
Fig. 2-25:
Fig. 2-27:
The excavator driver and the maintenance personnel must informthemselves about how to handle the fire-extinguisher in order to be able to act fast and efficiently in case of beginning fires. Such instruction should be given by a qualified instructor.
Pull out securing pin (2, Fig. 2-27:).
Extinguishing agent Each fire-extinguisher is filled with 12 kg (26.4 lb) Glutex. This extinguishing agent is used for fighting fires of classes A, B and C. Fires are extinguished fast, perfectly and without residues.
Fire extinguisher (option)
Strike knob (3) hard, then release again. Operate the extinguishing gun.
Inspection Have the extinguisher inspected at regular intervals by an expert. This is required by local authorities and insurance companies and is in the interest of your own safety. Have the fire-extinguisher checked at the prescribed intervals by authorized testing agencies.
The fire extinguishers can be installed, for instance, at the places indicated by the arrows (Fig. 2-26:).
Fig. 2-26:
