OPERATING INSTRUCTIONS RH120E Operation Sign Warning and instruction signs Observe the warning and instruction signs attached to the machine.
Keep the signs legible and clean. Replace signs immediately if they have become illegible. New warning and instruction signs can be ordered from the Bucyrus HEX Spare Parts Service. The ordering part numbers are set out in the spareparts list of the machine.
Fig. 2-4:
Fig. 2-2: shows the location of warning and instruction signs on the machine.
Machine number The identification plate (Fig. 2-4:) with the machine number is attached to the front side of the A-frame (arrow, Fig. 2-3:).
Engine number The serial number plate (Fig. 2-5:) for the diesel engine is located on the diesel engine.
Fig. 2-5: Fig. 2-3:
Component numbers Other larger units also have identification plates indicating, among other things, their serial number. On steel components, the Bucyrus HEX part number or the serial number may be stamped into the metal at a clearly visible place.
BA RH120E(3 725 023.00)-EN
2-11
