OPERATING INSTRUCTIONS RH120E Inspection and servicing Function The control elements of the lubricating system areinstalled on the panel (3). The grease is. pumped by the pumps (1 and 3, Fig. 3-141:) via greasing lines from the grease container to the main distributors on the superstructure and on the undercarriage.
Fig. 3-142:
As soon as the grease container is empty, the BCS (2, Fig. 3-143:) gives a warning signal. In the event of a fault, the "dumping" function is switched off automatically after 15 min. Fig. 3-141:
Work can be continued when the grease container is filled with grease.
The control elements of the lubricating system are installed on the panels (3 and 21, Fig. 3-142:).
Fig. 3-143:
