OPERATING INSTRUCTIONS RH120E Inspection and servicing Filling in engine oil Fill in engine oil through filler tube (2, Fig. 3-18:) until the oil level has reached the "max" mark (Fig. 3-19:) on dipstick (1).
Fig. 3-19:
Start the engines and allow to run at idling for abt. 2 minutes. Fig. 3-18:
Filling in engine oil through the service station (optional)
Check oil level at dipstick (1, Fig. 3-18:) and top up with oil to the "max" mark (Fig. 3-19:if required.
Fill in engine oil through express coupling (8, Fig. 3-20:) for the lefthandengine
express coupling (9) for the righthand engine
until the oil level has reached the "max." mark (Fig. 3-19:) on dipstick (1, Fig. 3-18:). Unscrew cap of epress coupling and connect filling hose of the service vehicle. The hose line and its use are described in the "hose line for oil and cooling liquid change" section. Fig. 3-20:
Remove the filling hose. The epress coupling closes automatically. Screw on protective cap.
