BUCYRUS INTERNATIONAL, Inc. 495HD Electric Mining Shovel
COLLECTOR RINGS High voltage collector rings, on bottom of the revolving frame, transfer electric power from the truck frame to the rotating deck. Electric power enters the truck frame just below the propel motor and is transferred by means of collector ring shoes to the collector rings. The shoes are mounted between the cast center pintle hub and the swing rack.
July 2005
1 - 21
Manual No. 10338
