BI617000
Bucyrus International, Inc. 495HD Electric Mining Shovel
The Calibration screen is used to set the various limits required to control the movements of the machine. On this screen can be found switches for the hoist, crowd and swing brakes along with status indicators for each. The limit settings can be found on the left side of the display area. The white text box near the bottom of the display area displays the current positions of the components.
Calibration Help
This screen will provide clarifying information on the calibration process.
Manual No. 10429
60
Aug. 2006
