Bucyrus International, Inc. 495HD Electric Mining Shovel
START PUSHBUTTON A pushbutton that, when pressed, will power up the drive system. The system ready light will go out. PLC POWER ON A green light that indicates the status of the PLC. DRIVE CABINET TEMPERATURE A green light that indicates temperature in the drive cabinet is neither too low nor too high. INCOMPLETE SEQUENCE A red light that indicates an incomplete sequence of startup events. SYSTEM READY A green light that indicates that the drive system is ready to start, but not yet started. PHASE SEQUENCE A green light that indicates that the phase sequence is okay in the incoming power. AUXILIARY GROUND FAULT A green light that when lit, indicates that no auxiliary power ground fault exists. If the light is off, alert an electrician as soon as possible. HOIST BRAKE A selector switch used to set or release the Hoist Brake. CROWD BRAKE A selector switch used to set or release the Crowd Brake. SWING BRAKE A selector switch used to set or release the Swing Brake. PROPEL BRAKE Manual No. 10429
46
Aug. 2006
