Section VII - Compressor Fluids
Quincy Compressor Fluid Analysis 2300 James Savage Road Midland, Michigan 48642-6535 UNDENIABLY THE WORLD’S FINEST COMPRESSORS
Sampling Procedures Preferred sample location is the fluid filter. If unable to take sample from fluid filter, proceed as follows: 1. Shutdown and lockout compressor. 2. Relieve pressure in reservoir. 3. Remove plug from reservoir drain line. 4. Drain water from reservoir and discard in approved manner. 5. Fill sample bottle with fluid. 6. Close valve and replace plug in drain line. 7. Return compressor to service and check fluid level during operation. Service with fluid as required. Using fluid filter sample valve, proceed as follows: 1. Open valve, drain 2-4 ounces of fluid from filter and discard in an approved manner. 2. Fill sample bottle. 3. Close valve. After collecting sample from either of the above methods: 1. Fill out information label completely.* Be certain to provide all information as to possible hazards related to a given sample. If this situation exists, all information shall be clearly marked on the sample bottle label. 2. Attach Sample Bottle Label to the bottle and put bottle in mailer. 3. Place Shipping Label on the outside of the mailer and send it by UPS. FROM:________________________________________
FROM:
Customer Fax #_________________________________ Model No._____________ Serial No._ ______________ Fluid__________________ Sample Date_____________
TO:
Quincy Compressor Fluid Analysis
Hours on Fluid_________ Hours on Machine________
2300 James Savage Road
Distributor______________________________________
Midland, MI 48642-6535
Sample From
o Reservoir
o Filter
Sample Bottle Label
Shipping Label
Note: A fluid sample valve kit is available from Quincy Compressor. Contact the Service Department and ask for part number 143286.
Quincy Compressor-QGB™
