Bucyrus International, Inc. 8200 Walking Dragline
DOOR OPERATION (Refer to the nameplate located near the control panel on the rear wall.) To OPEN one of the doors: 1.
Press the START button on the control panel to activate the hydraulic system.
2.
Press the UNLOCK button for the particular door to be opened. The green indicator light be lit.
3.
Open the top door using Valve #1 on the same side of the machine as the door to be opened.
4.
Open the inboard side door using Valve #2.
5.
Open the outboard side door using Valve #3.
6.
Press the STOP button on the control panel to deactivate the hydraulic system.
To CLOSE one of the doors: 1.
Press the START button on the control panel to activate the hydraulic system.
2.
Close the outboard side door using Valve #3 on the same side of the machine as the door to be closed.
3.
Close the inboard side door using Valve #2.
4.
Close the top door using Valve #1.
5.
Press the LOCK button for the particular door to be closed. The green indicator light should go out.
6.
Press the STOP button on the control panel to deactivate the hydraulic system.
