Bucyrus International, Inc. 8200 Walking Dragline
OPERATOR CONTROLS IN THE MACHINERY HOUSE
Power Control Room
The Power Control Room (PCR) encloses the electrical control components, preventing contamination from dirt, grease and dust. The segregation of control components into a room type module centralizes the responsibility of the electrician, thus improving maintenance. The Power Control Room is supplied with a constant source of clean, filtered air which is under pressure to afford the ideal environment for the efficient operation of the electrical components. The Starting Panel Controls used by the operator to start up and shut down the machine are located in the machinery house, near the center of the rear wall of the Power Control Room (PCR).
Manual No. 10238
46
Dec. 2004
