Bucyrus International, Inc. 8200 Walking Dragline
OPERATOR’S CAB AND ANTEROOM The Operator’s Cab and Anteroom extend from the right front corner of the rotating frame. This position provides the operator with an unobstructed view of the pit and spoil area, plus the boom point and bucket. The cab and anteroom area provides a controlled environment for the operator, crew, and electronic equipment.
Operator’s Cab - Anteroom
The cab contains the controls, switches, and indicators necessary for machine operation. These machine controls have been positioned in the cab to provide the operator with comfortable operation of the primary controls and easy access to all the secondary controls. The operator’s cab has two video monitors linked to seven closed circuit television camera’s located strategically around the machinery house. This will provide the operator with the ability to see in locations normally not visible while facing the work area. The operator’s cab has a phone system connected to receivers located at strategic points inside the machinery house and around the machine. This system provides easy communication between persons in the cab and elsewhere about the machine. A combination heater-defroster/air conditioning unit is mounted on the cab roof. Ducts from it to the floor area surround the operator for comfort and visibility. The control for this unit is on forward side of the operators cab rear wall.
