STEERING AND BRAKING SYSTEM 340-7751 ROTATING GP-MOTOR–STEERING S/N: GHS1-UP; MLW1-UP PART OF 309-1916 MOTOR GP-PISTON
SMCS-5058 NOTE
J
B B Y B B B B B B M
i03549340
REF NO
GRAPHIC REF
1 2
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
3 4 5 6 7 8 9 10 11 12 13 14 15 16
PART NAME PART NUMBER
340-7766 9T-2560 7X-1553 9T-2584 133-8739 2H-3928 9T-2581 9T-2582 310-7794 141-0250 141-0252 141-0249 141-0248 141-0247 141-0251 123-3299 113-4417
QTY
1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 7
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
SHAFT & BEARING AS COVER SEAL-LIP TYPE RING-RETAINING (INTERNAL) SEAL-LIP TYPE SEAL-O-RING SHIM (0.1-MM THK) SHIM (0.3-MM THK) BARREL GP-MOTOR SHIM (3.8-MM THK) SHIM (4-MM THK) SHIM (3.7-MM THK) SHIM (3.6-MM THK) SHIM (3.5-MM THK) SHIM (3.9-MM THK) PLATE-RETAINING SCREW (M6X1X16-MM)
433
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY J 171-5990 B-USE AS REQUIRED J-KIT MARKED J SERVICES PART MARKED J M-METRIC PART Y-SEPARATE ILLUSTRATION
452
STEERING AND BRAKING SYSTEM
1
AVAILABLE REPAIR KIT(S): KIT-BEARING
1 of 2
SEBP5016-20
