STEERING AND BRAKING SYSTEM 341-1510 HEAD GP-PUMP–STEERING S/N: GHS1-UP; MLW1-UP PART OF 320-8637 PUMP GP-PISTON
SMCS-5070 NOTE
Y M
Y
i03566528
REF NO
GRAPHIC REF
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
PART NAME PART NUMBER
117-7280 117-7282 117-7279 6V-8397 5W-1250 087-4772 152-1811 8C-4365 117-7278 120-4394 9S-4182 6V-8978 123-7575 212-6679 9S-8002 123-7583 177-6854 277-6679 3J-7354
QTY
1 1 1 1 2 2 1 4 1 3 2 1 1 1 1 1 1 2 2
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
BUSHING (INTERNAL) SEAL-O-RING BUSHING (EXTERNAL) SEAL-O-RING PIN PLUG-O-RING VALVE GP-RELIEF (PRESSURE OVERRIDE) BOLT (M14X2X80-MM) BUSHING PLUG-BREAK OFF PLUG-O-RING SEAL-O-RING SCREW-LOCK VALVE GP-RELIEF (CHARGE PRESSURE) PLUG-O-RING ORIFICE PLUG-PIN VALVE GP-RELIEF (CROSSOVER) SEAL-O-RING
463
464
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY M-METRIC PART Y-SEPARATE ILLUSTRATION
