UNDERCARRIAGE 108-0800 TRACK ADJUSTER & RECOIL GP S/N: GHS1-UP; MLW1-UP PART OF 271-6129, 351-5114 FRAME GP-TRACK ROLLER ALSO AN ATTACHMENT
SMCS-4157, 4158 NOTE
REF NO
GRAPHIC REF
i02297985 PART NAME PART NUMBER
1 1 190-8609 2 1 2S-5926 3 1 3W-2369 4 1 8G-3102 5 1 8G-4945 6 1 8G-4960 C 7 1 215-1594 8 1 251-8609 9 1 108-0801 10 1 2J-6274 11 1 2S-4078 12 1 8E-4092 M 13 1 8T-0375 14 1 8T-4121 M 15 1 8T-4182 16 1 9S-8010 17 1 9X-8268 C-CHANGE FROM PREVIOUS TYPE M-METRIC PART
SEBP5016-20
1 of 2
QTY
1 1 1 1 1 1 1 1 1 1 1 2 4 2 2 1 4
1
2
3
4
5
6
SEE PAGE
(PRODUCT LEVEL)
VALVE-FILL (RECOIL SPRING OIL) VALVE-RELIEF PLATE AS PISTON SEAL AS RETAINER TUBE AS SPRING CYLINDER SEAL-O-RING SEAL-O-RING RETAINER BOLT (M16X2X45-MM) WASHER-HARD (11X21X2.5-MM THK) BOLT (M10X1.5X45-MM) PLUG WASHER (17.5X30X3.5-MM THK)
UNDERCARRIAGE
409
